Frequency converter (with all-pole sinusoidal filter) / Triac
Classification
IP protection rating
IP54
Certifications
CE
Insulation class (DIN EN 60085)
F
Efficiency rating (ErP)
E15
Rated values 50 Hz
Elektrische Nennleistung
0.94
kW
Nominal voltage single-phase
230
V
Nominal current single-phase
4,2
A
Speed
840
U/min
Ambient temperature
-25 - 55
°C
Sound power level Lw
74
dB
Sound pressure level Lp
49
dB
Volumetric flow rate 50 Hz
Characteristic curve – 0 Pa
24700
m³/h
Characteristic curve – 10 Pa
23634
m³/h
Characteristic curve – 20 Pa
22451
m³/h
Characteristic curve – 30 Pa
21262
m³/h
Characteristic curve – 40 Pa
19505
m³/h
Characteristic curve – 50 Pa
17961
m³/h
Characteristic curve – 60 Pa
16229
m³/h
Characteristic curve – 70 Pa
14438
m³/h
Characteristic curve – 80 Pa
11946
m³/h
Characteristic curve – 90 Pa
8657
m³/h
Characteristic curve – 100 Pa
5067
m³/h
Spec. power 50 Hz
Characteristic curve – 0 Pa
32.1
W/(1000m³/h)
Characteristic curve – 10 Pa
34.6
W/(1000m³/h)
Characteristic curve – 20 Pa
37.4
W/(1000m³/h)
Characteristic curve – 30 Pa
40.2
W/(1000m³/h)
Characteristic curve – 40 Pa
44.3
W/(1000m³/h)
Characteristic curve – 50 Pa
48.6
W/(1000m³/h)
Characteristic curve – 60 Pa
53.9
W/(1000m³/h)
Characteristic curve – 70 Pa
61.3
W/(1000m³/h)
Characteristic curve – 80 Pa
73.9
W/(1000m³/h)
Characteristic curve – 90 Pa
101.9
W/(1000m³/h)
Characteristic curve – 100 Pa
176.4
W/(1000m³/h)
Characteristic curve – 110 Pa
417.1
W/(1000m³/h)
