Frequency converter (with all-pole sinusoidal filter) / Triac
Classification
IP protection rating
IP54
Certifications
CE
Insulation class (DIN EN 60085)
F
Efficiency rating (ErP)
E15
Dimensions
Width
1010
mm
Height
1070
mm
Total depth
261
mm
Diameter
1010
mm
Rated values 50 Hz
Elektrische Nennleistung
0.94
kW
Nominal voltage single-phase
230
V
Nominal current single-phase
4,2
A
Speed
840
U/min
Ambient temperature
-10 - 40
°C
Sound power level Lw
74
dB
Sound pressure level Lp
49
dB
Volumetric flow rate 50 Hz
Characteristic curve – 0 Pa
22761
m³/h
Characteristic curve – 10 Pa
21655
m³/h
Characteristic curve – 20 Pa
20604
m³/h
Characteristic curve – 30 Pa
19588
m³/h
Characteristic curve – 40 Pa
18460
m³/h
Characteristic curve – 50 Pa
17459
m³/h
Characteristic curve – 60 Pa
16466
m³/h
Characteristic curve – 70 Pa
15358
m³/h
Characteristic curve – 80 Pa
13640
m³/h
Spec. power 50 Hz
Characteristic curve – 0 Pa
38.4
W/(1000m³/h)
Characteristic curve – 10 Pa
41.1
W/(1000m³/h)
Characteristic curve – 20 Pa
43.6
W/(1000m³/h)
Characteristic curve – 30 Pa
46.4
W/(1000m³/h)
Characteristic curve – 40 Pa
49.5
W/(1000m³/h)
Characteristic curve – 50 Pa
52.9
W/(1000m³/h)
Characteristic curve – 60 Pa
56.1
W/(1000m³/h)
Characteristic curve – 70 Pa
60.5
W/(1000m³/h)
Characteristic curve – 80 Pa
67.3
W/(1000m³/h)
Illustrations may show accessories that are not included in the scope of delivery.
Due to constant further development of our products, illustrations and technical data may deviate slightly. Errors and omissions excepted.
