Mot-g 0,37 230/460 60 1,7/0,9A 9C 19r(6-90Hz) lb-driveUL/CSA

SKU

90-00-4032

Sales unit 1 pc

Dimensions
Length	426.00	mm
Width	268.00	mm
Height	181.00	mm
Actual weight	19.865	kg

Basic data
Design electric motor	B14
Motor size	90S

Rated values
Frequency	60	Hz
Pole pair	60

Classification
IP protection rating	IP55	IP
Certifications	UL, CSA

Rated values 60 Hz
Nominal power	0,37	kW
Nominal voltage delta connection	230	V
Nominal voltage star connection	460	V
Current consumption delta connection	2	A
Current consumption star connection	1,1	A
Motor speed	1730	r/min
Nominal torque motor	2,04	Nm
Gear speed	20	r/min

Illustrations may show accessories that are not included in the scope of delivery.
Due to constant further development of our products, illustrations and technical data may deviate slightly. Errors and omissions excepted.
